Verisurf Inspection Suite

The Verisurf 3D Scanning and Inspection Suite integrates Verisurf’s CAD and ANALYSIS modules and tackles inspection challenges head-on. Verisurf’s unique, CAD-based architecture can read any file format and has the most flexible reporting capabilities available. Create colorful deviation plots highlighting any nonconformance between measured parts and nominal CAD—all in a Windows-standard graphical interface that always delivers a superior user experience

• Includes Verisurf CAD and ANALYSIS modules.
  • Extract measured features with GD&T and fit clouds or meshes
  • Analyze deviation to CAD nominal with clear Pass/Fail balloons
  • Identify nonconformance and produce custom quality reports
  • Automate inspection with accurate repeatable scan data process
• Flexible best fit options reduce scrap and rework
• Embed stunning color results in your reports
• Fastest align-inspect-report
• Measure any 2D or 3D feature type
• Memorize steps to create reusable plans
• Full MBD (GD&T) import and annotation
• Compare as-built to any nominal CAD source
• Advanced best fit increases conformance rates
• Easily import any 3D scan point cloud or STL mesh.
• Automatically extract and analyze scan data to CAD model nominals and quickly produce intelligent GD&T reports
• Save reusable, automated inspection plans to support production inspection.

Verisurf Reverse Engineering Suite

Verisurf’s 3D Scanning and Reverse Engineering Suite includes CAD and REVERSE modules and is uniquely suited for any reverse engineering project. The suite features an extensive set of tools for editing, meshing, and surfacing pointcloud and mesh data. Because all Verisurf solutions are CAD based, the suite also includes an extensive toolset for completing the 3D CAD model using your measurement or scan data.

Verisurf is fully compatible with the Mastercam NC programming application—allowing you to measure, mesh, and model your part and then use Mastercam (sold separately) to program and drive CNC or additive manufacturing equipment to complete the manufacturing process using a single file

Quickly import any 3D scan point cloud or STL mesh. Create 3D printable STL models for additive
manufacturing, 3D surfaces for industrial design and rapid machining or complete solid models with intelligent GD&T for manufacturing.

Verisurf’s Scan Data Reverse Engineering Suite features an extensive set of tools for managing, combining, filtering, editing, meshing, and surfacing both pointcloud and mesh data.

• • Create manufacturable CAD models from physical parts
  • Align multiple, scanned pointcloud objects with ease
  • Automate surface meshing using pointclouds and meshes
  • Create CAD geometry from pointcloud or mesh cross sections
• Import scan or probe data from any device. You can even start with a drawing
• Verify solid model to part conformance
• Extensive pointcloud meshing and surfacing tools
• Align multiple pointclouds to each other or to CAD
• Fit contiguous smooth surfaces through pointclouds and meshes with Power Surface
• Extensive editing, smoothing, and best fit tools

Features of the EinScan HX :

Hybrid Blue Laser & LED Light

Innovatively integrated with dual blue LED light and blue laser, improves scanning materials adaptability with less limitation for a wider range of applications. LED light scanning allows rapid 3D scanning. Laser scanning, which is less sensitive to ambient light, gives better performance to reflective and dark color surface.

Reliable Results

The high resolution and accuracy meet the needs of most industrial applications for reverse engineering and measuring.
